Analogue / Cartridges
EAT JO Nº5
RETAIL PRICE: 1 190,00 €
PRICE: 600,00 €
CONDITION: 9/10
COLOR: Green
INCLUDES: Box, manual, brush and screws and nuts
AGE:
LOCATION: Portugal
WARRANTY: Not applicable
DESCRIPTION
Low output moving-coil cartridge. The Noº 5 uses an aluminum cantilever to which is affixed a “Fine Line” stylus. The coil windings are made of pure 4N copper. The JO Nº5 combines the richness and warmth of some other modestly priced MCs with a good deal of the detail and resolution produced by more expensive MCs. Stylus Profile: Nude Fine Line. Output voltage: 0.33 mV (5cm/sec). Cartridge Weight: 15 g. Frequency Response: 20Hz-26kHz +/-1.5dB. Channel Separation at 1 kHz / 15 kHz: > 25dB > 16 dB. Channel Balance at 1 kHz: > 1.2 dB. Compliance, Dynamic/Lateral: 12 µm/mN. Recommended Tracking Force: 2.4g (24 mN) . Tracking Angle: 20º. Recommended Load Impedance: > 20 Ohm. Internal Impedance, DC Resistance: 5 Ohm.
SITE: https://www.europeanaudioteam.com/
SERIAL NUMBER: 180
