DESCRIPTION |
|
Mytek`s first commercial amplifier for the domestic market, the Brooklin Amp is a dual-mono stereo amplifier in a class D design. Bi-amped or bridged operation available, user-selectable – bridging can be done via internal DIP switches. An amplifier with superb dynamics, striking resolution and spacious soundstages. Specifications: (2) Inputs: (1) balanced (XLR) and (1) single-ended (RCA). Output power in dual-mono/stereo and bi-amp modes (1kHz, 1% THD+N): 250Wpc into 8 ohms (24dBW), at 300Wpc into 4 ohms (21.7dBW), and at 400Wpc into 2 ohms (20dBW). Output power in bridged mode (1kHz, 1% THD+N): 600W into 8 ohms (24.7dBW). Maximum peak output current: 35A. Frequency response: 10Hz–30kHz, +0/–3dB. Gain: 23 or 29dB, selectable. Input impedance: 10k ohms. Output impedance: 0.025 ohm. THD+N (1kHz at 1W): 0.002%. THD+N (typical): <0.04% (20Hz–20kHz, 8 ohm load, 3dB below rated power). Signal/noise: >121dB (A-weighted, 20Hz–20kHz, 8 ohm load). Power consumption: idle, 0.23W, working, same as output power + 12%. |
|
